The fischer FAZ II GS bolt anchor with large washer is the steel anchor for the highest demands. The steel anchor made of galvanised steel is used to fix heavy loads in cracked concrete. The FAZ II GS can be used particularly flexibly thanks to its simple installation. The tried-and-tested expansion clip guides the loads particularly securely into the concrete and enables the highest load-bearing capacity.
- Pre-assembled washer for components with slotted holes. This makes alignment easier and saves time during installation.
- Minimised tightening slip: Simple installation reduces time and effort.
- With expansion clip for maximum daylight capability: This means that fewer fixing points and smaller anchor plates are required. This saves time and costs.
- Approval for cracked concrete and fire testing: maximum safety.
Klaus-Fischer-Straße 1
72178
Waldachtal D
07443/12-0
info@fischer.de
| Anchor system: | mechanical |
|---|---|
| Article type: | Bolt anchor |
| Assembly technology: | Screws & spreaders |
| Authorisation for materials: | cracked and non-cracked concrete C20/25 to C50/60 |
| Brand: | fischer |
| Contents (st): | 50 |
| Diameter (mm): | 8 |
| Drill-Ø (mm): | 8 |
| Drill hole depth min (mm): | 65 |
| Length (mm): | 75 |
| Manufacturer: | Fisherman |
| Manufacturer designation: | Bolt on |
| Material dowel & anchor: | Steel |
| Model: | FAZ II gvz 8/10 GS |
| Suitable for concrete: | True |
| Test mark: | ETA-05/0069 |
| suitable for: | SW13 |
