Quick and easy installation without cleaning the drill hole (M8-M24). Decisive increase in the transverse load-bearing capacity thanks to the new assessment (ETA) - fewer fixing points and smaller anchor plates save time and money. Maximum durability is guaranteed by the external test certificate of the FAZ II Plus over a service life of 120 years (M10-M16).
The variable anchoring depths enable millimetre-precise adaptation to the loads. Numerous test certificates for different substrate materials (concrete C12/15-C80/90, steel fibre concrete (aBG), solid sand-lime brick) increase the number of fields of use and application.
Manufacturer "fischer Deutschland Vertriebs GmbH"
fischer Deutschland Vertriebs GmbH
Klaus-Fischer-Straße 1
72178
Waldachtal D
07443/12-0
info@fischer.de
Klaus-Fischer-Straße 1
72178
Waldachtal D
07443/12-0
info@fischer.de
| Anchor system: | mechanical |
|---|---|
| Article type: | Bolt anchor |
| Assembly technology: | Screws & spreaders |
| Authorisation for materials: | Concrete C20/25 to C50/60 - cracked and non-cracked |
| Brand: | fischer |
| Contents (st): | 50 |
| Diameter (mm): | 10 |
| Drill-Ø (mm): | 10 |
| Drill hole depth min (mm): | 85 |
| Length (mm): | 95 |
| Manufacturer: | Fisherman |
| Manufacturer designation: | Bolt anchor |
| Material dowel & anchor: | Steel |
| Model: | FAZ II Plus 10/10 |
| Suitable for concrete: | True |
| Test mark: | ETA-19/0520 |
| suitable for: | SW17 |
| Hersteller |
| Produktinformation |
0 of 0 reviews
Average rating of 0 out of 5 stars
Login
No reviews found. Share your insights with others.
Fischer bolt anchor FAZ II Plus 10/10 PU=50
Product number:
7040434438
EAN:
4048962462043
€105.32
Content:
50
STÜCK
(€2.11 / 1 STÜCK)
Delivery time of 4 business days once payment has been received
