The fischer long-shaft plug SXR-T is a frame plug made of high-quality nylon with a pre-assembled fischer safety screw with countersunk head. Thanks to the special anchor geometry, the SXR can be used in solid and perforated building materials. Due to the shallow anchoring depth of just 50 mm, the long-shaft plug is particularly economical to use for multiple fixings in non-load-bearing systems. The fischer long-shaft plug SXR-T with countersunk head screw is particularly recommended for fixing timber constructions.
- Low anchoring depth saves time and costs.
- Expansion in solid building materials.
- Knotting in perforated building materials.
- With safety screw.
- ETA approval in concrete and masonry.
Klaus-Fischer-Straße 1
72178
Waldachtal D
07443/12-0
info@fischer.de
| Anchoring depth min. (mm): | 50 |
|---|---|
| Article type: | Long shank dowel |
| Assembly technology: | Screws & spreaders |
| Authorisation for materials: | Beton ? C12/15, Hochlochziegel, Hohlblock aus Leichtbeton, Kalksand-Lochstein, Kalksand-Vollstein, Porenbeton, Vollblock aus Leicht- und Normalbeton, Vollziegel, Wärmedämmblöcke |
| Brand: | fischer |
| Contents (st): | 50 |
| Diameter (mm): | 10 |
| Dowel/anchor with edge: | True |
| Drill-Ø (mm): | 10 |
| Drill hole depth min (mm): | 110 |
| Length (mm): | 100 |
| Manufacturer: | Fisherman |
| Manufacturer designation: | Long shank dowel |
| Material dowel & anchor: | Nylon |
| Model: | SXR 10x100 T |
| Scope of delivery: | 50 x pre-assembled safety screw with countersunk head (T40 drive) |
| Suitable for aerated concrete: | True |
| Suitable for concrete: | True |
| Suitable for gypsum fibreboards: | False |
| Suitable for insulating materials: | False |
| Suitable for natural stone: | True |
| Suitable for panel building materials: | False |
| Suitable for perforated bricks: | True |
| Suitable for plasterboard: | False |
| Test mark: | ETA approval |
