The fischer SXRL FUS long-shaft plug with the fischer hexagon safety screw with moulded washer and integrated T40 bit holder is approved for multiple fixings of non-load-bearing systems in masonry, concrete and aerated concrete. In perforated brickwork, the two expansion zones of the plug apply force evenly, while in aerated concrete and solid building materials they combine to form one long expansion element. With the safety screw made of galvanised steel, the long shank plug is suitable for indoor fixings such as windows, wardrobes, wall cupboards or TV consoles.
- Holding forces are transferred evenly into the building material thanks to the anchor geometry. This means that webs are not destroyed in thin-walled building materials.
- Easy installation: ribs prevent the plug from turning when it is inserted deeper.
- Maximum holding forces in aerated concrete and solid building materials: the two expansion zones combine to form a long expansion element.
- ETA approval: secure multiple fixing of non-load-bearing systems in concrete and masonry.
Klaus-Fischer-Straße 1
72178
Waldachtal D
07443/12-0
info@fischer.de
| Article type: | Long shank dowel |
|---|---|
| Assembly technology: | Screws & spreaders |
| Authorisation for materials: | Perforated brick, aerated concrete, hollow block made of lightweight concrete, perforated sand-lime brick, thermal insulation blocks, solid block made of lightweight and normal concrete, solid brick, solid sand-lime brick, concrete ? C12/15 |
| Brand: | fischer |
| Contents (st): | 50 |
| Dowel/anchor with edge: | True |
| Drill-Ø (mm): | 10 |
| Drill hole depth min (mm): | 110 |
| Length (mm): | 100 |
| Manufacturer: | Fisherman |
| Manufacturer designation: | Long shank dowel |
| Material dowel & anchor: | Nylon |
| Model: | SXRL 10x100 FUS |
| Scope of delivery: | Hexagon head screw with washer |
| Suitable for aerated concrete: | True |
| Suitable for concrete: | True |
| Suitable for insulating materials: | True |
| Suitable for perforated bricks: | True |
| Suitable for solid bricks: | True |
| Test mark: | ETA-07/0121 |
| suitable for: | TX40,SW13 |
| Hersteller |
| Produktinformation |
0 of 0 reviews
Average rating of 0 out of 5 stars
Login
Fischer long-shaft dowel SXRL 10x100 FUS PU=50
€107.10
