HECO-TOPIX , disc head, T-Drive

The properties of the HECO-TOPIX disc head are completely designed for structural timber construction. It has a larger head diameter and, thanks to this enlarged clamping surface, can bear significantly higher loads than countersunk head screws. At the same time, it significantly reduces the number of fixing points required. The partially threaded version has shank ribs that reduce the screw-in torque and create a stress-free connection. The optimised thread pitch makes screwing in easier and quicker. In addition, the patented HECO-TOPIX point ensures a reduced splitting effect and enables fast screwing without pre-drilling or countersinking. The result: fast and secure installation with up to 30 per cent less processing effort.

Product strengths

  • No pre-drilling necessary
  • Faster screwing in
  • Significant reduction in the splitting effect
  • Lower screw-in torque
  • Higher load transmission due to enlarged clamping surface of the head
  • Approved and monitored product
  • HECO HCS design verification or design service
Manufacturer "Heco Schrauben GmbH & Co. KG"
Heco Schrauben GmbH & Co. KG


Dr-Kurt-Steim-Str. 28
78713
Schramberg D
07422 - 9890
info@heco-schrauben.de
More products from Heco Schrauben GmbH & Co. KG
Article type: Wood construction screw
Brand: HECO screws
Diameter (mm): 8
Head drive: TX
Head shape: Plate head
Length (mm): 300
Manufacturer: Heco screws
Manufacturer designation: Topix disc head screw
Material screws: Steel
Shank milling ribs: true
Standard: ETA-11/0284
Suitable for wood: true
Surface treatment of hardware: blue galvanised
Tested by building authorities: true
Thread division: Partial thread
Thread pitch: Coarse thread
Thread type: Wood thread
suitable for: TX40
