HECO-UNIX-TOP fully threaded screw

HECO-UNIX the fully threaded screw with the contraction effect in the HECO-UNIX-plus and HECO-UNIX-top versions
The HECO-UNIX has a full thread with a variable pitch
This decreases steadily in the centre area and is smaller in the rear thread area than in the tip area of the screw
Due to the variable thread pitch of the HECO-UNIX, the timber components are pulled together when screwed in
This means that fully threaded screws can also be used for timber-to-timber connections without having to preload them
This makes the work easier and significantly faster
The components are additionally fixed axially by the full thread
This prevents the negative effects of creep and shrinkage of the wood when using partially threaded screws
In addition, panel materials are already clamped to the substructure before the head support is reached
The head therefore does not have to be countersunk unnecessarily deep
Tip with milling ribs, for gap-free screwing in with small screw spacings

Manufacturer "Heco Schrauben GmbH & Co. KG"

Heco Schrauben GmbH & Co. KG

Dr-Kurt-Steim-Str. 28
78713
Schramberg D
07422 - 9890
info@heco-schrauben.de

Article type:	Fully threaded screw
Brand:	HECO screws
Contents (st):	100
Diameter (mm):	6.00
Head drive:	TX
Head shape:	Countersunk head
Length (mm):	150.00
Manufacturer:	Heco screws
Material screws:	Steel
Milling ribs lower head:	true
Standard:	ETA-11/0452
Suitable for aluminium & sheet metal:	false
Suitable for metal:	false
Suitable for plastic:	false
Suitable for wood:	true
Surface treatment of hardware:	blue galvanised, A2K, anti-friction coated
Tested by building authorities:	true
Thread division:	Solid thread
Thread pitch:	Coarse thread
Thread type:	Wood thread
suitable for:	TX 30
