MULTI-MONTI TC, MMS-TC TimberConnect, T-Drive

The innovative MULTI-MONTI-TimberConnect (MMS-TC) sleeper anchor combines the patented MULTI-MONTI concrete thread with a HECO timber thread. The MMS-TC therefore ensures simple and secure fastening of timber components to solid masonry and concrete as well as sleepers to concrete. The sleeper anchor has all the advantages of the concrete thread: no torque control, small edge distances and no curing times. It also gives the installer a special advantage, as the small head of the MMS-TC can be countersunk into the wood. This means that one screw anchor is sufficient for all wood thicknesses. The MMS-TC is screwed together mechanically in push-through installation using a setting tool. The unique combination of different design concepts allows significantly higher tensile and shear loads. In addition, the transferable tensile and shear loads are not dependent on the thickness of the fixture.

Product strengths

Quick and easy installation
Machine setting possible without any problems
Can be loaded immediately
Can be dismantled
No torque control required
High level of safety
Approved and monitored product for cracked and non-cracked floors

Manufacturer "Heco Schrauben GmbH & Co. KG"

Heco Schrauben GmbH & Co. KG

Dr-Kurt-Steim-Str. 28
78713
Schramberg D
07422 - 9890
info@heco-schrauben.de

More products from Heco Schrauben GmbH & Co. KG

Article type:	Wood construction screw
Brand:	HECO screws
Contents (st):	25
Diameter (mm):	12
Head drive:	TX
Head shape:	MMS-TC TimberConnect
Length (mm):	160
Manufacturer:	Heco screws
Manufacturer designation:	MMS-TC TimberConnect screw anchor
Material screws:	Steel
Standard:	Z-21.1-1879
Suitable for aluminium & sheet metal:	true
Suitable for concrete:	true
Suitable for plastic:	true
Suitable for wood:	true
Surface treatment of hardware:	blue galvanised, A2K
Tested by building authorities:	true
Thread division:	Solid thread
Thread pitch:	Coarse thread
Thread type:	Concrete thread
suitable for:	TX 50
