Pavatex Isolair wood fibre insulation board

Multifunctional diffusion-open wood fibre insulation board
Available in several formats for use as insulation and underlay board
Insulation board for ventilated facades
Plaster base insulation board with ETICS approval PAVACASA for wooden substrates and as a flat roof insulation board
Also available in large format for prefabrication
Particularly economical thanks to versatile areas of application and double-sided use
Multifunctional use as type UDP-A sarking board, plaster base and insulation board for rear-ventilated façades and flat roofs
Windproof, water-repellent and vapour-permeable insulation board for secure constructions

Manufacturer "Soprema GmbH"

Soprema GmbH

Mallaustraße 59
68219
Mannheim D
0621/736030
info@soprema.de

Area of application Insulation materials:	Roof, ceiling, wall
Area of application Insulation materials according to DIN 4108-10:	DAD–ds, DAA-ds, DI–zg, DEO–ds, WAB–ds, WI–zg, WAP-zh
Article type:	Insulation board
Brand:	SOPREMA
Compressive stress (kPA):	200
Deck length (mm):	1861
Deck width (mm):	591
ETICS:	Yes
Edge formation Insulation materials:	Tongue & groove
Fire protection class:	B2
Insulation material:	Wood fibre
Length (mm):	1880
Manufacturer:	Soprema
Manufacturer designation:	Insulation and underlay board
Nominal value of thermal conductivity ?D (W/mK):	.044
Rated value of thermal conductivity ? (W/mK):	.046
Series:	ISOLAIR
Surface insulation materials:	smooth
Thickness (mm):	35
Use of insulating materials:	External insulation of roof or ceiling, protected from weathering, insulation under coverings, external insulation of wall behind cladding, external insulation of wall under plaster, internal insulation of wall
Width (mm):	610
