Designo top-hung windows - WDF R88CK W WD AL 11/14
Roto

Optionally in timber or PVC design
Maximum headroom when the window is open thanks to 45° opening angle
Free access to the window and perfect view, swing function up to the stop
Bottom single-handed operation with 4-point central locking system
Quick installation thanks to comprehensive pre-assembly ex works; can also be subsequently adapted to any installation situation thanks to practical adjustment options
Simple and safe ventilation; when the window is closed, the two-stage gap ventilation ensures fresh air supply
Convenient and safe maintenance thanks to self-locking cleaning position

Manufacturer "Roto Frank DST Vertriebs-GmbH"

Roto Frank DST Vertriebs-GmbH

Wilhelm-Frank-Straße 38-40
97980
Bad Mergentheim-Ed. D
07931/5490-0
info@rotofrank.de

Article type:	Hinged top hung window
Brand:	Roto
Colour:	Inside: white
Frame material:	Plastic
Glazing:	2-fold
Glazing variant:	Comfort
Length window size/frame dimension (cm):	140.0
Manufacturer:	Roto
Material outer cover:	Aluminium
Model:	R8
Operation:	manually
Permitted roof pitch:	20°- 65°, with wedge flashing from 15°
Series:	Designo
Size designation Light & vision:	11/14
Sound insulation class window:	2
Sound reduction index window (dB):	34.0
Type of glazing:	2-fold
Uw value window (W(m²K)):	1.1
Width window size/frame size (cm):	114.0
