The aerodynamically optimised ventilation of the Venduct® room ventilator thanks to the pipe geometry, air guide ring and
Air guide ring and rain bonnet reduces turbulence to a minimum and ensures effective exhaust air performance - particularly
with fan-assisted exhaust air. Any condensate that accumulates is channelled safely to the outside
to the outside above the roof covering.
The Venduct® room air vent - suitable for Venduct® base plates and Venduct® universal base plates -
is suitable for motorised ventilation in kitchens and bathrooms in accordance with DIN 18017 or as a waste water pipe aerator
venduct® room air vents can be used for any roof made of clay tiles, concrete roof tiles, slate and corrugated sheets,
Slate and corrugated sheets.
Safety information:
In winter, condensation can form on the weather cap, the vapour pipe itself and/or on the roof passage pipe in unfavourable weather conditions
itself and/or on the roof tile. To prevent uncontrolled slipping, we recommend
suitable safety measures, such as the installation of two snow guard hooks in the watercourses of the through tile
and/or the underlying pan.
Recommendation:
Weather cap on: active ventilation (e.g. with fans) of rooms or equipment.
Weather cap off: Ventilation of waste water pipes.
Marke Klöber
Scharpenberger Str. 72-90
58256
Ennepetal D
+49 6104 8010 1700
info.kloeber@bmigroup.com
| Article type: | Ventilation and deaeration pipe |
|---|---|
| Brand: | Klöber |
| Colour: | dark brown |
| Diameter (mm): | 100.0 |
| Manufacturer: | Klöber |
| Manufacturer designation roof system parts: | Vent pipe |
| Material roof system parts: | Plastic |
| Material specification roof system parts: | Special PVC |
| Series: | Venduct® |
| Weight (kg): | 0.88 |
| suitable for: | Connection 100 mm with joint and rain cover |
| Hersteller |
| Produktdatenblatt |
0 of 0 reviews
Average rating of 0 out of 5 stars
Login
Klöber Venduct® ventilation pipe long KE8009 DN100 dark brown
€84.73
