Venduct® DN 100 ventilation pipe
Room vent with condensate drainage

The aerodynamically optimised ventilation of the Venduct® room ventilator through pipe geometry,
Air guide ring and rain bonnet reduces turbulence to a minimum and ensures effective exhaust air performance
- especially with fan-assisted exhaust air. Any condensate that accumulates is channelled safely
safely to the outside above the roof covering. The Venduct® room air vent - suitable for
Venduct® base plates and Venduct® universal base plates - is suitable for motorised ventilation in kitchens and bathrooms in accordance with
and bathrooms in accordance with DIN 18017 or as a waste water pipe aerator in accordance with DIN 1986 T 100. Venduct® room air vents can be used
for any roof made of clay tiles, concrete roof tiles, slate and corrugated sheets.

Safety information:
In winter, condensation can cause ice to form on the weather cap, the vent pipe itself and/or on the roof tile in unfavourable weather conditions.
To prevent uncontrolled slipping, we recommend suitable safety measures, such as the installation of two snow guard hooks in the watercourses of the through-roof pan and/or the pan below.

Recommendation:
Weather cap up: active ventilation (e.g. with fans) of rooms or appliances.
Weather cap off: Ventilation of waste water pipes.

Product benefits
High ventilation properties Simple installation Wide range of colours Reliable condensate drainage

Area of application
The Venduct ® room air vent - suitable for Venduct ® base plates and Venduct ® universal base plates
- is suitable for motorised ventilation in kitchens and bathrooms in accordance with DIN 18017 or as a waste water pipe air vent in accordance with DIN 1986 T 100.
Venduct ® room air vents can be used for any roof made of clay tiles, concrete roof tiles, slate and corrugated sheets
